Fork 1600x100x45, Class 2A
Ochrona Kupującego Trusted Shops
product unavailable
add to wish list
Description
Lifting fork designed for installation on ISO 2328 / FEM Class 2A forklift carriages. Manufactured from solid forged steel and fully heat-treated to ensure high bending strength and resistance to material fatigue during intensive material handling operations. Features integrated top and bottom hooks with a locking pin for secure positioning on the carriage plate.
Technical Specification:
-
Part Type: Forklift fork (hook-on / FEM-type fork)
-
Width: 100 mm
-
Thickness: 45 mm
-
Usable Length: 1600 mm
-
Mounting Class: FEM 2A
-
Capacity per Pair: 3000 kg
-
Load Centre: 500 mm
-
Quality: High-grade replacement matching OEM specification and ISO 2328 / ISO 2330 standards
-
Applications: Forklift trucks equipped with FEM Class 2A carriage
Technical data
| Total height | 45 mm |
| Overall width | 100 mm |
| Overall length | 1600 mm |
| Quality of parts | OEM - oryginal |
| Weight | 67,6 kg |
